Specifications

Expand all

Overview

Capacity (Cooling, Btu/hr)

11260Btu/hr

Capacity (Cooling, kW)

3.30kW

EER (Cooling, W/W)

3.22W/W

Net Dimension

720*548*265mm

Capacity

Capacity (Cooling, Btu/hr)

11260 Btu/hr

Capacity (Heating, Btu/hr)

13000 Btu/hr

Capacity (Cooling, Min - Max, Btu/hr)

2,250 ~ 14,300 Btu/hr

Capacity (Heating, Min - Max, Btu/hr)

1,600 ~ 14,300 Btu/hr

Capacity (Cooling, kW)

3.30 kW

Capacity (Heating, kW)

3.81 kW

Capacity (Cooling, Min - Max, kW)

0.66 ~ 4.19 kW

Capacity (Heating, Min - Max, kW)

0.47 ~ 4.19 kW

Energy Efficiency

EER (Cooling, W/W)

3.22 W/W

COP (Heating, W/W)

3.42 W/W

EER (Cooling, Btu/hW)

10.99 Btu/hW

COP (Heating, Btu/hW)

11.66 Btu/hW

Noise Level

Noise Level (Indoor, High/Low, dBA)

41 / 21 dBA

Noise Level (Outdoor, High/Low, dBA)

49 dBA

Electrical Data

Power Source(Φ/V/Hz)

1 / 220-240 / 50

Power Consumption(Cooling, W)

1025 W

Power Consumption(Heating, W)

1115 W

Operating Current(Cooling, A)

5.0 A

Operating Current(Heating, A)

5.2 A

Physical specification

Gross Dimension (Indoor, WxHxD, ㎜*㎜*㎜)

880*290*375 mm

Gross Dimension (Outdoor, WxHxD, ㎜*㎜*㎜)

844*622*353 mm

Net Dimension (Indoor, WxHxD, ㎜*㎜*㎜)

820*299*215 mm

Net Dimension (Outdoor, WxHxD, ㎜*㎜*㎜)

720*548*265 mm

Gross Weight (Indoor, kg)

10.5 kg

Gross Weight (Outdoor, kg)

30.0 kg

Net Weight (Indoor, kg)

9.2 kg

Net Weight (Outdoor, kg)

27.0 kg

Loading Quantity (20/40/40Hft without Pipe)

96 / 197 / 232

Technical Information

Piping Length (Max, m)

15 m

Piping Height (Max, m)

7 m

SVC Valve (Liquid (ODxL))

6.35

SVC Valve (Gas (ODxL))

9.52

Moisture Removal (l/hr)

1.5 l/hr

Air Circulation (Cooling, ㎥/min)

10.9 ㎥/min

Refrigerant (Type)

R410A

Refrigerant (Charging, kg)

0.97 kg

Refrigerant (Charging, tCO2e)

2.03 tCO2e

Low Ambient (Cooling, ℃)

16~52 ℃

Low Ambient (Heating, ℃)

-10~24 ℃

Outdoor Unit (Compressor Type)

BLDC

Outdoor Unit (Anti-Corrosion Fin)

Yes

Air Flow

Air Direction Control (Up/Down)

Auto

Air Direction Control (Left/Right)

Manual

Air Flow Control Step (Cool/Fan)

5/4

Air Purification

PM 1.0 Filter

No

Tri Care Filter

No

Easy Filter Plus (Anti-Bacteria)

Yes

Auto Clean (Self Cleaning)

Yes

Convenience

SmartThings

No

AI Auto Cooling

No

Motion Detect Sensor

No

Filter Cleaning Indicatior

Yes

Indoor Temp. Display

Yes

Display On/Off

Yes

Beep On/Off

Yes

24-Hour Timer

Yes

Auto Changeover

Yes

Auto Restart

Yes

Operating Mode

Auto Mode

Yes

Fast Cool

Yes

Good Sleep

Yes

Eco Mode

Yes

Dehumidification

Yes

Fan Mode

Yes

Quiet

Yes

Smart

WiFi Embedded

No

App Connectivity

SmartThings App Support
