CoreTECH NexGEN Pv12000 6kW Hybrid Inverter. Price in Pakistan on Installments
Specifications & Features
Installment Plan
Latest Price
Why Buy from Us
What is the price of CoreTECH NexGEN Pv12000 6kW Hybrid Inverter.?
What is the installment plan?
What are the specifications?
Description
FAQs
| MAX. PV access power | 12000W |
| Max. PV input power | 9kW |
| Max. input voltage | 550V |
| Rated PV input voltage | 360V |
| Start-up voltage | 60V |
| MPPT voltage range | 90-450V |
| Max. PV input current | 20A/20A |
| Max. short circuit current | 30A/30A |
| MPPT number/Max. input strings number | 2/2 |
| BATTERY | |
| Battery type | Lead-acid or Li-ion |
| Rated battery voltage | 48V |
| Battery voltage rang | 40-60V |
| Max. charge / discharge current | 135A/135A |
| Communication | CAN/RS485 |
| Charging strategy for Li-ion battery | Self-adaption on to BMS |
| AC OUTPUT | |
| Rated output power | 6kW |
| Max. apparent output power | 6.6kVA |
| Rated output voltage | 220V/230V,L/N/PE |
| Output voltage range | 160V-300V |
| Rated output frequency/frequency range | 50Hz/60Hz (±5Hz) |
| Rated output current | 26.1A |
| Max.output current | 28.7A |
| power factor | power factor >0.99(0.8 leading - 0.8 lagging) |
| THDi | <3% |
| AC INPUT | |
| Rated input power | 6kW |
| Max. input power | 9.2kW |
| Rated input voltage | 220V/230V,L/N/PE |
| Rated input frequency | 50/60Hz |
| Max. input current | 40A |
| BACK-UP OUTPUT | |
| Rated output power | 6kW |
| Max. output power | 2 Times of rated power, 10 s |
| Rated output voltage | 220V/230V,L/N/PE |
| Rated output frequency | 50/60Hz |
| Max. output switch me | 28.7A |
| Back-up switch me | <4ms |
| THDv | <3% |
| EFFICIENCY | |
| MPPT efficiency | 99.80% |
| Max. efficiency | 97.70% |
| EU efficiency | 96.70% |
| BAT charged/discharged Max efficieny | 95.3% / 93.9% |
| PROTECTION | |
| Integrated DC switch | Yes |
| DC rever-polarity protec on | Yes |
| Insula on impedance detec on | Yes |
| Residual leakage current detec on | Yes |
| Ground fault monitoring | Yes |
| Short circuit protec on | Yes |
| An -islanding protec on | Yes |
| DC/AC surge protec on | DC:Type ll;AC:Type ll |
| DC arc-fault circuit protec on | Optional |
| I/V curve scanning | Yes |
| Parallel connec on number of inverter | Max.16 |
| GENERAL | |
| Opera ng temperature range | -40 to 60°C |
| Max. opera on al tude | 4000m(Dera ng above 3000m) |
| Rela ve humidity | 0~100% |
| Cooling concept | Smart Fan Cooling |
| Ingress protection | IP 66 |
| Topology | Transformerless |
| Self consump on(night) | ≤20W |
| Dimensions (W*H*D) | 350*620*260mm |
| Weight | 28kg |
| Type of PV terminal | MC4 connector |
| Type of PV terminal (Grid side) | Terminal |
| Warranty | 10 Years* |
| COMMUNICATION | |
| Display | LCD+LED+Bluetooth+APP |
| Communication | WIFI+Bluetooth,Op onal:GPRS,LAN ;BMS:RS485/CAN |
| CERTIFICATION | |
| Grid standards | IEC 61727/62116,IEC 61683,PEA |
| Safety/EMC | IEC/EN 62109-1/2,IEC/EN 62477-1, EN IEC61000-6-1/2/3/4 |
